ASRock Rack 8U16X-GNR2 B300 HGX B300 NVL8 270GB Air-Cooled (8) Intel Granite Rapids (2) AI Graphics Card GPU Server

8U16X-GNR2 B300

  1. 930 x 448 x 353.6mm (36.6” x 17.6” x 13.9”)
  2. 8U Rackmount with 6+6, 80-PLUS Titanium, 3000W CRPS
  3. NVIDIA HGX™ B300 NVL8 with NVIDIA NVLink™
  4. Dual Socket E2 (LGA 4710), supports Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors
  5. 16+16 DIMM slots (2DPC); supports DDR5 RDIMM, RDIMM-3DS, MRDIMM
  6. 4 FHHL PCIe5.0 x16
  7. 12 Hot-swap 2.5″ NVMe (PCIe5.0 x4) drive bays
  8. Supports 1 M.2 (PCIe5.0 x2), 2 M.2 (PCIe5.0 x4)
  9. 8 OSFP (800Gb/s) via NVIDIA ConnectX-8 SuperNIC
  10. 2 RJ45 (1GbE) by Intel® i350-AM2
  11. Remote management (IPMI)

Original price was: $1,969,900.00.Current price is: $1,899,900.00.

Payment Methods:
Add to compare
Add to wishlist
11 People watching this product now!

Contact

Hurry and get discounts on all product. sales@catalogone.com

Shipping

Shipping solutions for the selected different quantity are currently available by Air: DHL,Fedex,UPS,EMS,Aramex or different Countries Logistics Air line.

Description

Specifications

 System
Form Factor 8U Rackmount
Dimensions 930 x 448 x 353.6mm (36.6” x 17.6” x 13.9”)
Support Motherboard GNR2D32G-2L+
 Front Panel
Buttons UID button w/ LED, power button w/ LED, reset button, NMI button,
LEDs System fault LED, HDD activity LED
I/O Ports 8 OSFP (800Gb/s) via NVIDIA® ConnectX-8 SuperNIC
2 RJ45 (1GbE) by Intel i350, shared with rear IO
1 dedicated IPMI, shared with rear IO
4 Type-A (USB3.2 Gen1)
1 DB15 (VGA)
 External Drive Bay / Storage
Front Side Drive Bay 12 Hot-swap 2.5″ NVMe (PCIe5.0 x4) drive bays [PCIe switch]
Internal Side 1 M-key (PCIe5.0 x2), supports 22110/2280 form factor [CPU0]
2 M-key (PCIe5.0 x4), supports 22110/2280 form factor [CPU1]
 Power Supply
Type 6+6 CRPS
Output Watts 3002.4W @ 220-240Vac input, 2900W @200-220Vac input
Efficiency 80-PLUS Titanium
AC Input 200-240Vrms, 50/60Hz
 System Fan
Fan 26 PWM 80×80 mm fans, 6 PWM 60×56 mm fans
 Processor System
GPU NVIDIA® HGX™ B300 NVL8
CPU Supports Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series Processors
Socket 1+1 Socket E2 (LGA 4710)
Chipset System on Chip
 System Memory
Supported DIMM Quantity 16+16 DIMM slots (2DPC)
Supported Type DDR5 RDIMM, RDIMM-3DS
DDR5 MRDIMM (1DPC only)
Max. Capacity per DIMM RDIMM: 128GB
RDIMM-3DS: 256GB
MRDIMM: 64GB
Max. DIMM Frequency RDIMM, RDIMM-3DS: 6400MT/s (1DPC), 5200MT/s (2DPC)
MRDIMM: 8000MT/s (1DPC only)
Voltage 1.1V
 PCIe Expansion Slots
PCIe x 16 Rear: 4FHHL PCIe5.0 x16 [PCIe switch]
 Ethernet
Additional Ethernet Controller Intel® i350: 2 RJ45 (1GbE)
NVIDIA® ConnectX-8 SuperNIC: 8 OSFP (800Gb/s)
 Server Management
BMC Controller ASPEED AST2600: IPMI2.0 with iKVM and vMedia support
Dedicated IPMI LAN 1 Realtek RTL8211F for dedicated management GLAN
 Graphics
Controller ASPEED AST2600
VRAM DDR4 512MB
 Rear I/O
UID Button/LED 1 UID button w/LED
Other Button/LED 1 power button w/LED, 1 reset button, 1 NMI button, 1 HDD activity LED, 1system fault LED
Video Port 1 DB15 (VGA)
USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (1GbE) by Intel® i350, shared with front IO
1 dedicated IPMI, shared with front IO
 System BIOS
BIOS Type AMI UEFI BIOS; 512Mb SPI Flash ROM
BIOS Features Plug and Play, ACPI 4.0 and above compliance wake up events, SMBIOS 3.4 and above, ASRock Rack instant flash
 Hardware Monitor
Temperature CPU, MB, Card side Temperature Sensing
Fan Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
Fan Multi-Speed Control
Voltage P0_VDDCR_CPU0, P0_VDDCR_CPU1, P0_VDDCR_SOC, P0_VDD_18_DUAL, P0_VDD_11_S3, P0_VDDIO, P1_VDDCR_CPU0, P1_VDDCR_CPU1, P1_VDDCR_SOC, P1_VDD_18_DUAL, P1_VDD_11_S3, P1_VDDIO, +BAT, +12V, +3VSB, +5VSB
 Environment
Temperature Operating temperature: 10°C ~ 35°C / Non-operating temperature: -40°C ~ 70°C
Humidity Non-operating humidity: 20% ~ 90% (non-condensing)

The specification is subject to change without notice in advance. ASRock Rack is the official trademark for ASRock Rack Inc., all the covers need to remain the original brand name without any modification. All other brands, names and trademarks are the property of their respective owners.

Memory QVL

Type Speed↓ DIMM Size↓ Vendor↑ Module Part No Cell
DDR5 8800 MRDIMM 96GB Micron MTC40F204WS1HC88XC1 WCCC 4XC7DD8GGR Micron
DDR5 8800 MRDIMM 96GB Micron MTC40F204WS1HC88XB1 WCCC 4OB77D8DCM Micron
DDR5 6400 RDIMM 96GB Micron MTC40F204WS1RC64BC1 QSFF 5PC75D8GGR Micron
DDR5 6400 RDIMM 96GB Samsung MDRRWM4QDBC2-3G000 PDRQW4DCBG12 Sec
DDR5 6400 RDIMM 64GB Hynix HMCG94AHBRA480N H5CG44AHBD X018 Hynix
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BH1 QSFF 5LH75D8HLF Micron
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BH1 3XCC 5MH75D8HLF Micron
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BH1 3SFF 5LH75D8HLF Micron
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BH1 2XCC 5LH75D8HLF Micron
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BD2 QWCC 4GD45D8DKR Micron
DDR5 6400 RDIMM 64GB Micron MTC40F2046S1RC64BD2 QSFF 4GD45D8DKR Micron
DDR5 6400 RDIMM 64GB Samsung M321R8GA0EB2-CCPWF K4RAH04 6VEBCCP Sec
DDR5 6400 RDIMM 64GB Samsung MDRR644QDBC2-3D000 PDRQL4DCBG12 Sec
DDR5 6400 RDIMM 16GB Micron MTC10F1084S1RC64BD2 QSFF 4GD45D8DKT Micron
DDR5 5600 RDIMM 128GB Micron MTC40F2047S1RC56BB2 QLFF 4XB75D8GDF Micron

HDD QVL

Type Size Vendor Capacity Model
U.3 2.5″ Micron 3.84TB 7500 PRO-MTFDKCC3T8TGP-1BK1JABYY
U.2 2.5″ KIOXIA 30.72TB CD8P-R SERIES-KCD8XPUG30T7
U.2 2.5″ SAMSUNG 7.68TB PM1743-MZWLO7T6HBLA-00A07
U.2 2.5″ SAMSUNG 3.84TB PM1743-MZWLO3T8HCLS-00A07
U.2 2.5″ SAMSUNG 3.84TB PM9D3A-MZWL63T8HFLT-00AW7
U.2 2.5″ SAMSUNG 1.92TB PM1743-MZWLO1T9HCJR-00A07
U.2 2.5″ SOLIDIGM 3.84TB D7-PS1010-SB5PH27X038T
