ASRock Rack GPU Server 8U8X-EGS2 SYN B200 HGX B200 NVL8 180GB Air-Cooled (8) Intel Emerald Rapids (2)

8U8X-EGS2 SYN B200

  1. 930 x 448 x 353.6mm (36.6″ x 17.6″ x 13.9″)
  2. 8U Rackmount with 6+6, 80-PLUS Titanium, 3000W CRPS
  3. NVIDIA HGX™ B200 8-GPU with NVIDIA NVSwitch™
  4. Optimized performance of GPU-to-CPU, GPUDirect RDMA NIC, and GPUDirect Storage by PCIe Switch Synthetic Mode
  5. Dual Socket E (LGA 4677), supports 5th and 4th Gen Intel® Xeon® Scalable Processors
  6. 16+16 DIMM slots (2DPC), supports DDR5 RDIMM, RDIMM-3DS
  7. 8 HHHL PCIe5.0 x16, 2 FHHL PCIe5.0 x16
  8. 8 Hot-swap 2.5″ NVMe (PCIe5.0 x4) drive bays [PCIe switch]
  9. 2 Hot-swap 2.5″ NVMe (PCIe5.0 x4) [CPU]/ SATA [PCH] drive bays
  10. 2 Hot-swap 2.5″ SATA drive bays [PCH]
  11. Supports 1 M.2 (PCIe3.0 x4 or SATA 6Gb/s), 1 M.2 (PCIe3.0 x4)
  12. 2 RJ45 (1GbE) by Intel® i350-AM2
  13. Remote management (IPMI)

Original price was: $469,900.00.Current price is: $399,900.00.

Payment Methods:
Add to compare
Add to wishlist
16 People watching this product now!

Contact

Hurry and get discounts on all product. sales@catalogone.com

Shipping

Shipping solutions for the selected different quantity are currently available by Air: DHL,Fedex,UPS,EMS,Aramex or different Countries Logistics Air line.

Description

Specifications

 System
Form Factor 8U Rackmount
Dimensions 930 x 448 x 353.6mm (36.6” x 17.6” x 13.9”)
Support Motherboard SP2C741D32G-2L+
 Front Panel
Buttons Power button w/ LED, Reset button, NMI button, UID button
LEDs System fault LED, HDD activity LED
I/O Ports 2 RJ45 (1GbE) by Intel i350, shares with Rear IO
1 dedicated IPMI, shares with Rear IO
4 Type-A (USB3.2 Gen1)
1 DB15 (VGA)
 External Drive Bay / Storage
Front Side Drive Bay 8 Hot-swap 2.5″ NVMe (PCIe5.0 x4) drive bays [PCIe switch]
2 Hot-swap 2.5″ NVMe (PCIe5.0 x4) [CPU]/ SATA [PCH] drive bays
2 Hot-swap 2.5″ SATA drive bays [PCH]
Internal Side 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 2280/22110 form factor [PCH]
1 M-key (PCIe3.0 x4), supports 2280/22110 form factor [PCH]
 Power Supply
Type 6+6 CRPS
Output Watts 3002.4W @ 220-240Vac input, 2900W @200-220Vac input
Efficiency 80-PLUS Titanium
AC Input 200-240Vrms, 50/60Hz
 System Fan
Fan 29 PWM 80×80 mm fans + 4 PWM 40×40 mm fans
 Processor System
GPU NVIDIA® HGX B200 8-GPU with NVIDIA® NVSwitch™
CPU Supports 5th and 4th Gen Intel® Xeon® Scalable Processors
Socket Dual Socket E (LGA 4677)
Thermal Design Power Up to 350W
Chipset C741
 System Switch Board
Switch IC PEX89104
Topology Synthetic mode for optimized performance of GPU-to-CPU, GPUDirect RDMA NIC, and GPUDirect Storage
 System Memory
Supported DIMM Quantity 16+16 DIMM slots (2DPC)
Supported Type Supports DDR5 288-pin RDIMM, RDIMM-3DS
Max. Capacity per DIMM RDIMM: 96GB
RDIMM-3DS: 2H- 128 GB / 4H- 256 GB
Max. DIMM Frequency 5600 MT/s (1DPC) / 4400 MT/s (2DPC) on 5th Gen Intel® Xeon® Scalable Processors
4800 MT/s (1DPC) / 4400 MT/s (2DPC) on 4th Gen Intel® Xeon® Scalable Processors
*Memory speed and capacity support varies by CPU SKU
Voltage 1.1V
 PCIe Expansion Slots
PCIe x 16 Rear:
8 HHHL PCIe5.0 x16
2 FHHL PCIe5.0 x16
 Ethernet
Additional Ethernet Controller Intel® i350: 2 RJ45 (1GbE)
 Server Management
BMC Controller ASPEED AST2600
Dedicated IPMI LAN 1 Realtek RTL8211F for dedicated management GLAN
 Graphics
Controller ASPEED AST2600
VRAM DDR4 512MB
 Rear I/O
UID Button/LED 1 UID button
Video Port 1 DB15 (VGA)
USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (1GbE) by Intel® i350, shares with Front Panel
1 dedicated IPMI, shares with Front Panel
 System BIOS
BIOS Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
BIOS Features ASRock Rack Instant Flash, ACPI 6.4 and about compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
 Hardware Monitor
Temperature CPU, MB, Card side Temperature Sensing
Fan Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
Fan Multi-Speed Control
Voltage P0_VDDCR_CPU0, P0_VDDCR_CPU1, P0_VDDCR_SOC, P0_VDD_18_DUAL, P0_VDD_11_S3, P0_VDDIO, P1_VDDCR_CPU0, P1_VDDCR_CPU1, P1_VDDCR_SOC, P1_VDD_18_DUAL, P1_VDD_11_S3, P1_VDDIO, +BAT, +12V, +3VSB, +5VSB
 Environment
Temperature Operating temperature: 10°C ~ 35°C / Non-operating temperature: -40°C ~ 70°C
Humidity Non-operating humidity: 20% ~ 90% (non-condensing)

The specification is subject to change without notice in advance. ASRock Rack is the official trademark for ASRock Rack Inc., all the covers need to remain the original brand name without any modification. All other brands, names and trademarks are the property of their respective owners.

Memory QVL

Type Speed↓ DIMM Size↓ Vendor↑ Module Part No Cell
DDR5 6400 RDIMM 96GB Micron MTC40F204WS1RC64BC1 QSFF 5PC75D8GGR Micron
DDR5 6400 RDIMM 64GB Hynix HMCG94AHBRA480N H5CG44AHBD X018 Hynix
DDR5 6400 RDIMM 64GB Samsung MDRR644QDBC2-3D000 PDRQL4DCBG12 Sec
DDR5 6400 RDIMM 64GB Samsung M321R8GA0EB2-CCPWC K4RAH046VE BCCP Sec
DDR5 5600 RDIMM 96GB Micron MTC40F204WS1RC56BB1 IMCC 3IB75D8DCL Micron
DDR5 5600 RDIMM 64GB Micron MTC40F2046S1RC56BD2 MLCC 51D75D8DKQ Micron
DDR5 5600 RDIMM 64GB Micron MTC40F2046S1RC56BD1 MMCC 3SD4DD8DKQ Micron
DDR5 5600 RDIMM 64GB Samsung M321R8GA0PB0-CWMXH K4RAH046VP BCWM Sec
DDR5 4800 RDIMM 96GB Micron MTC40F204WS1RC48BB1 IGFF 3LB75D8DHL Micron
DDR5 4800 RDIMM 64GB Micron MTC40F2046S1RC48BA1 MGCC IXA47D8BNH Micron
DDR5 4800 RDIMM 64GB Samsung M321R8GA0BB0-CQKZJ K4RAH046VB BCQK Sec
DDR5 4800 RDIMM 64GB SMART SR8G8RD5445-SB K4RAH046VB BCQK Sec
DDR5 4800 RDIMM 32GB Micron MTC20F2085S1RC48BA1 JGFF 3FA45D8BNJ Micron

HDD QVL

Type Size Vendor Capacity Model
U.3 2.5″ Micron 960GB 7500 PRO-MTFDKCC960TGP-1BK1DABYY
U.2 2.5″ FADU 7.68TB DELTA-FSNE40U2DC7T60020
U.2 2.5″ KIOXIA 30.72TB CD8P-R SERIES-KCD8XPUG30T7
U.2 2.5″ SAMSUNG 960GB PM9A3-MZQL2960HCJR-00A07
